| Model | Dimensions (mm) | Typical Application |
|---|---|---|
| Size Group A: Compact & Standard | ||
| JXF-200-300-160 | 200 x 300 x 160 | Compact control units, small terminal distribution |
| JXF-300-400-160 | 300 x 400 x 160 | Standard distribution box, entry-level panel |
| JXF-300-400-200 | 300 x 400 x 200 | Basic electrical cabinet with moderate capacity |
| JXF-400-500-160 | 400 x 500 x 160 | Shallow-depth panel for space-limited installations |
| JXF-400-500-200 | 400 x 500 x 200 | Versatile mid-size box for general purpose wiring |
| JXF-500-600-160 | 500 x 600 x 160 | Wide, shallow enclosure for horizontal component layout |
| JXF-500-600-200 | 500 x 600 x 200 | Common size for industrial control panels |
| JXF-600-600-200 | 600 x 600 x 200 | Square profile box for balanced internal layout |
| Size Group B: Large & High-Capacity | ||
| JXF-300-400-250 | 300 x 400 x 250 | Deep box for dense wiring or multiple DIN rails |
| JXF-400-600-200 | 400 x 600 x 200 | Extended length for sequential component arrangement |
| JXF-400-600-250 | 400 x 600 x 250 | High-capacity terminal box for complex connections |
| JXF-500-600-250 | 500 x 600 x 250 | Deep, spacious enclosure for large components (e.g., VFDs) |
| JXF-500-700-200 | 500 x 700 x 200 | Large surface area panel for display/control modules |
| JXF-500-700-250 | 500 x 700 x 250 | Heavy-duty box for machinery main control panels |
| JXF-500-800-200 | 500 x 800 x 200 | Extended length panel for multi-circuit distribution |
| JXF-500-800-250 | 500 x 800 x 250 | Deep, long box for complex automation systems |
| Size Group C: Extra-Large & Custom Applications | ||
| JXF-600-700-200 | 600 x 700 x 200 | Large industrial main distribution board housing |
| JXF-600-700-250 | 600 x 700 x 250 | Extra depth for advanced PLC systems with accessories |
| JXF-600-800-200 | 600 x 800 x 200 | Wide panel for multi-zone control applications |
| JXF-600-800-250 | 600 x 800 x 250 | High-volume cabinet for data center or utility use |
| JXF-600-900-200 | 600 x 900 x 200 | Extended height panel for vertical component stacking |
| JXF-600-900-250 | 600 x 900 x 250 | Maximum capacity for integrated power & control systems |
| JXF-600-1000-200 | 600 x 1000 x 200 | Full-height enclosure for large-scale distribution |
| JXF-600-1000-250 | 600 x 1000 x 250 | Premium deep box for critical infrastructure projects |
| JXF-700-800-200 | 700 x 800 x 200 | Extra-wide panel for extensive instrumentation |
| JXF-700-800-250 | 700 x 800 x 250 | Wide and deep box for custom-built power panels |
| JXF-700-900-200 | 700 x 900 x 200 | Large-format enclosure for public utility applications |
| JXF-700-900-250 | 700 x 900 x 250 | Heavy-duty design for mining, energy, or marine sectors |
| JXF-800-1000-200 | 800 x 1000 x 200 | Jumbo-sized cabinet for main switchboards |
| JXF-800-1000-250 | 800 x 1000 x 250 | Top-tier enclosure for the most complex and demanding installations |
