Engineered for demanding industrial and high-rise applications, our wall-mounted distribution box is crafted from hot-dip galvanized steel for superior corrosion resistance.
With IP54/IP65 protection against dust and water ingress, it features a precision injection-molded door seal and integrated mounting plate for effortless installation.
Fully customizable in size and finish with OEM/ODM support, it accommodates 16A to 50A ratings across 48V to 480V—delivering robust, reliable power distribution with integrated overload and short-circuit protection.
| TECHNICAL PARAMETERS | |
|---|---|
| Product Name | Power Distribution Cabinet |
| Keywords | Distribution Box |
| Rated Voltage | 48V / 220V / 415V / 440V / 450V / 480V |
| Rated Current | 16A / 20A / 30A / 32A / 50A |
| Number of Sockets | 0 / 6 / 8 / 12 / 16 (Customizable) |
| Shell Material | Hot-Dip Galvanized Steel Plate |
| Door Plate Thickness | 0.8mm/ 1.0mm / 1.2mm |
| Dimensions (H×W×D) | 300-1000mm × 300-1000mm × 200-250mm |
| Size Customization | Fully Customizable |
| Surface Treatment | Powder Coating / Galvanization / Oxidization / Electrophoresis |
| Protection Features | Waterproof / Dustproof / Fireproof / Anti-theft |
| Safety Function | Overload & Short Circuit Protection |
| Installation Type | Wall-Mounted with Bottom Cable Exit Ports |
| IP Protection Rating | IP54 / IP65 |
| Application | Industrial / Commercial / High-rise Buildings |
| QS(JXF1) Foundation Box Series | |||||
|---|---|---|---|---|---|
| Model | Steel Plate Thickness (mm) | External Dimensions (mm) | |||
| Door Panel | Box | High | Width | Deep | |
| JXF1-4030/20C | 0.8 | 0.6 | 400 | 300 | 200 |
| JXF1-5040/20C | 500 | 400 | 200 | ||
| JXF1-6050/20C | 600 | 500 | 200 | ||
| JXF1-3040/20B | 1.0 | 0.8 | 300 | 400 | 200 |
| JXF1-4030/20B | 400 | 300 | 200 | ||
| JXF1-4050/20B | 400 | 500 | 200 | ||
| JXF1-5040/20B | 500 | 400 | 200 | ||
| JXF1-5040/25B | 500 | 400 | 250 | ||
| JXF1-5060/20B | 500 | 600 | 200 | ||
| JXF1-6050/20B | 600 | 500 | 200 | ||
| JXF1-6050/25B | 600 | 500 | 250 | ||
| JXF1-7050/20B | 700 | 500 | 200 | ||
| JXF1-6080/20B | 0.9 | 600 | 800 | 200 | |
| JXF1-8060/20B | 800 | 600 | 200 | ||
| JXF1-8060/25B | 800 | 600 | 250 | ||
| JXF1-80100/20B | 800 | 1000 | 200 | ||
| JXF1-10080/20B | 1000 | 800 | 200 | ||
| JXF1-10080/25B | 1000 | 800 | 250 | ||
| QS(JXF1) Thickened Foundation Box Series | |||||
|---|---|---|---|---|---|
| Model | Steel Plate Thickness (mm) | External Dimensions (mm) | |||
| Door Panel | Box | High | Width | Deep | |
| JXF1-4030/20A | 1.2 | 1.0 | 400 | 300 | 200 |
| JXF1-5040/20A | 500 | 400 | 200 | ||
| JXF1-6050/20A | 600 | 500 | 200 | ||
| JXF1-6050/25A | 600 | 500 | 250 | ||
| JXF1-7050/20A | 700 | 500 | 200 | ||
| JXF1-8060/20A | 800 | 600 | 200 | ||
| JXF1-8060/25A | 800 | 600 | 250 | ||
| JXF1-80100/20A | 800 | 1000 | 200 | ||
| JXF1-10080/20A | 1000 | 800 | 200 | ||
| JXF1-10080/25A | 1000 | 800 | 250 | ||
