Product Description
Equipment can be designed according to needs:
- Customizable various frequency conversion cabinets
- PLC control cabinets
- Energy-saving transformation projects
- Develop customized programming
- Industrial control cabinet
- Explosion-proof cabinet
- Generator synchronization panel
- ATS cabinet
- Distribution box
- Electrical cabinet
Distribution cabinet Functions
- Power Distribution: Transform high-voltage power from the external grid into low-voltage power suitable for hospital departments. Distribute it to branch circuits to power electrical and medical equipment, and lighting systems.
- Circuit Control and Protection: Use switches and circuit breakers to control circuit on-off for maintenance and emergency response. Provide overload, short-circuit, and leakage protection, cutting off circuits quickly in case of anomalies to safeguard equipment and personnel.
- Monitoring and Metering: Equip with voltmeters, ammeters, and power meters to display real-time power parameters like voltage, current, and power. Also, use an electric energy metering device for accurate power consumption statistics, facilitating cost accounting and energy management.
Component Structure
- Incoming Line Section: Consist of incoming line circuit breakers, isolating switches, and current transformers. The circuit breaker controls main power on-off and cuts off during failures. The isolating switch offers a clear disconnection point for maintenance, and the current transformer measures incoming current for protection and metering.
- Busbar: Usually made of copper or aluminum, it connects electrical components in the distribution cabinet, gathering and distributing power. It has good conductivity and mechanical strength to bear high currents.
- Outgoing Line Section: Contain multiple outgoing circuits, each with independent protection and control components such as circuit breakers, contactors, and thermal relays. These components distribute power according to department or equipment needs and protect circuits from overloads and short-circuits.
- Control and Protection Circuit: Comprise relays, fuses, and control switches to control, protect, and signal the main distribution cabinet. For example, control relays enable remote or automatic control, and fuses cut off faulty circuits during short-circuits.
- Instrument and Signal Devices: Include measuring instruments like voltmeters, ammeters, power meters, and watt-hour meters, along with signal devices such as indicator lights and alarm devices. Instruments monitor power parameters, and indicator lights and alarms show equipment operation status and fault information.
| Name |
Control cabinet/panel |
| Product type |
One control by one |
| Box/cabinet size |
Customizable |
| Box/cabinet thickness |
0.8/1.2/1.5mm |
| Instal type |
wall mounting/console mode |
| Component brand |
Schneider, ABB, Omron, DELIXI, Eaton, Siemens |
| Shell material |
Carbon steel, stainless steel, explosion-proof |
| major component |
Shell, circuit breaker, power input interface, distribution unit, protective device, and auxiliary equipment |
| Protection level |
IP40, IP44, IP54, IP65 |
| Type of AC power supply |
Single phase and three-phase |
| Box/cabinet thickness |
0.8/1.2/1.5mm |
| Box/cabinet size |
Customizable |
1
24-hour online contact
2
Provide us with detailed technical specifications
3
We will provide you with a quotation
4
Prepay 30% as a deposit
5
Design drawings to be produced within 3 days
6
Shell production takes 5-7 days
7
Assembly of components inside the cabinet
8
Support plc programming
9
Debugging the finished product
10
Packaging of goods
11
Pay the final payment
12
Delivery
Frequently Asked Questions
Are you a manufacturer?
Yes, we are a manufacturer. Our production facilities are equipped to handle design, assembly, and testing of electrical control panels and distribution systems.
What products can I purchase from you?
We offer complete sets of distribution boxes, distribution panels, control panels, control boxes, power supply cabinets, and electrical cabinets designed for industrial and electrical automation.
How can I place an order?
You can place an order by providing detailed technical specifications, single line diagrams (SLD), or project drawings. Our engineering team will review the requirements and provide a formal quotation.
How long does it take to get a quotation and what are the delivery times?
After receiving technical requirements, a quote is normally provided within 2 days. Sample production takes around 15 days, while mass production requires approximately 26 days depending on the volume and customization needs.
What are your standard payment terms?
We accept flexible payment terms, including an irrevocable letter of credit at sight, or a 30% deposit in advance with the remaining 70% balance payable after the goods are ready for delivery.
Do you offer on-site technical support?
Yes, our technical team is available to assist and provide guidance for on-site installation, testing, debugging, and general maintenance operations.
