This remarkable product operates efficiently within an ambient air temperature range, not exceeding +40 °C or dropping below -5 °C, ensuring optimal performance. The maximum average temperature within any given 24-hour period should remain under +35 °C.
Designed to thrive in varying humidity levels, the relative humidity should not surpass 50% at the peak temperature of +40 °C. However, it accommodates higher humidity at cooler temperatures, such as up to 90% when the temperature is +20 °C.
The environment should consist of clean air, devoid of any corrosive, explosive gases, or conductive and insulating dust, ensuring longevity and reliable operation.
Engineered for stability, this device should be installed vertically in locations free from pronounced shaking or shock vibrations, with an inclination not surpassing 5 degrees.
Designed for high-altitude performance, this product is suitable for installations where the altitude does not exceed 2000 meters above sea level.
During transportation and storage, the switch cabinet is resilient to temperatures ranging from -25 °C to +55 °C, and can temporarily withstand up to +70 °C for short durations not exceeding 24 hours.
Should there be conditions outside these parameters, users are encouraged to engage in discussions to tailor solutions that meet specific needs.
Provide detailed diagrams of the main circuit distribution system, including phase layout diagrams, alongside rated working voltage, current, and protection device parameters for precise customization.
Clearly specify the required specifications for both incoming and outgoing cables to ensure compatibility.
List the model, specification, and quantity of the main electrical components needed within the differential cabinet for seamless integration.
Should there be a need for bus extrusion or a bus duct between the switch and incoming cabinets, please indicate the specific requirements, including span and ground height measurements.
For applications within special environmental conditions, detailed specifications should be provided during the ordering process to ensure perfect adaptation.
Specify the desired surface color of the switch cabinet along with any additional specific requirements to match your design preferences.
The product operates efficiently within an ambient air temperature range of -5 °C to +40 °C. The average temperature over any 24-hour period should not exceed +35 °C.
At a peak temperature of +40 °C, the relative humidity should not exceed 50%. However, it can accommodate higher relative humidity at lower temperatures, reaching up to 90% at +20 °C.
The equipment is designed for high-altitude performance and is suitable for installations up to 2000 meters above sea level.
The cabinet can withstand storage and transportation temperatures between -25 °C and +55 °C, and can temporarily resist up to +70 °C for durations not exceeding 24 hours.
Please provide detailed main circuit distribution diagrams, incoming/outgoing cable specifications, the model and quantity of the main electrical components, bus duct specifications if required, and details on any special environmental parameters or custom surface colors.
