| Model NO. | Low Voltage Switchgear |
| Voltage Level | Low Voltage |
| Installation | Fixed |
| Structure | Cabinet |
| Current | AC |
| Transport Package | Export Standard Wooden Case |
| Specification | customized |
| Origin | China |
| HS Code | 8535210000 |
| Package Size | 400.00cm * 400.00cm * 300.00cm |
| Package Gross Weight | 100.000kg |
Discover the YBW series prefabricated substation, a masterful combination of high-voltage electrical equipment, transformers, and low-voltage electrical equipment. This compact and complete power distribution solution is expertly designed for various applications, including urban high-rise structures, rural developments, residential communities, high-tech zones, and small to medium factories. It is also ideal for mining, oil fields, and temporary construction sites, offering seamless distribution of electrical energy across diverse environments.
The YBW series prefabricated substation exudes excellence with its robust design, compact size, and state-of-the-art features. It promises safe and reliable operations, easy maintenance, and mobility. Compared to conventional civil substations, this innovative substation occupies merely 1/10 to 1/5 of the usual space, significantly cutting down on design workload and construction costs. It accommodates various power distribution systems like the thousand-ring network distribution or dual power sources, making it an essential upgrade for urban and rural substation infrastructure.
The YBW series prefabricated substation proudly adheres to the national standard of GB/T17467-1998 for 'High Voltage / Low Voltage Prefabricated Substations,' ensuring unmatched quality and reliability.
Kindly provide the following information prior to placing your order:
| NAME | Unit | High Voltage Electrical Equipment | Transformer | Low Voltage Electrical Equipment |
|---|---|---|---|---|
| Rated Voltage | KV | 10 | 10/0.4 | 0.4 |
| Rated Current | A | 630 | - | 100~2500 |
| Rated Frequency | Hz | 50 | 50 | 50 |
| Rated Capacity | KVA | - | 100~1250 | - |
| Rated Thermal Stability Current | KA | 20/45 | - | 30/15 |
| Rated Dynamic Current (peak) | KA | 50 | - | 63 |
| Rated Short Circuit Current (peak) | KA | 50 | - | 15~30 |
| Rated Breaking Short-circuit Current | KA | 31.5 | - | - |
| Rated Breaking Load Current | A | 630 | - | - |
| 1min Power Frequency Withstand Voltage | KV | to earth, between poles 42 | 35/28(5mln) | 2.0/2.5 |
| Lighting Impulse Withstand Voltage | KV | to earth, between poles 75 | 75 | - |
| Shell Protection Grade | - | IP33D / IP22D (Shell Of Transformer) | ||
| Noise Level | dB | - | ≤55 (Oil Transformer) / ≤65 (Dry Transformer) | - |
| Number of Loops | - | 1~6 | 2 | 4~30 |
| Maximum Reactive Power Compensation on the Low Voltage Side | Kvar | - | - | 300 |
